Discover our factory

Exploring the Intelligent Production Base - The Precision Evolution of Carbon Fiber Technology

10,000-level clean prepreg workshop

Constant temperature and humidity control (23±1℃, humidity 50%±5%)
Equipped with T700-level carbon fiber weaving system, supporting 1K-24K tow plain/twill/multi-axial weaving (width 1~2m, weight 80-600g/㎡ customizable)

Composite material molding center

6 large autoclaves (diameter 2.4-3.5m, pressure range 0.6-2.0MPa)
German LANGZAUNER molding production line (clamping force 800-3000 tons)


Precision machining and testing area

Five-axis linkage machining center (repeat positioning accuracy ±0.005mm)
Industrial CT non-destructive testing room (defect recognition accuracy 0.03mm³)

Vacuum-heat-press-machine-1
Vacuum heat press machine
Cutting-Machine-1
Cutting Machine
Vulcanizing-machine
Vulcanizing machine
CNC-engraving-machine
CNC engraving machine
Autoclave-machine
Autoclave machine

WHAT IS THE PRODUCTION PROCESS OF CARBON FIBER FABRIC/CLOTH?

Production process of carbon fiber cloth:
Hanging-yarn
1. Hanging yarn:
Hang the carbon filament on the yarn rack to prepare for the subsequent steps.
Threading-yarn
2. Threading yarn:
Pass the carbon fiber filament through each paddle and steel wire in an orderly manner to ensure that the yarn is neatly arranged.
Hanging-tail-wire
3. Hanging tail wire:
After heating, the tail wire will melt, thus binding the carbon filaments and preventing them from loosening.
Weaving
4. Weaving:
Selecting the right carbon filament quality and weaving process is crucial to the quality of the final finished carbon fiber fabric.
Winding
5. Winding:
When the carbon fiber cloth is woven to the set number of meters, the machine will automatically stop for the next operation.
Unloading-cloth
6. Unloading cloth:
Finally, the woven carbon fiber cloth is packaged and stored to complete the entire production process.
Through these steps, we are able to produce high-quality carbon fiber fabric/cloth to meet various needs.
Advanced Carbon
Fiber Solutions
At Suzhou Revolve CF New Material Co., Ltd., we have redefined various possibilities through cutting-edge carbon fiber solutions. To provide incomparable strength, lightweight, and sustainability for industries worldwide.
